DSC (R) series of pump FGD

Description

DSC (R) series of pump FGD
Capacity: 1083-2722L / a
Head: 26-27m
Speed: 550-740r / min
Material: high-chromium alloy and rubber

Detailed description

Hebei Delin Machinery is one of the biggest pump company, specializing in the production of slurry pumps in China, with a land area of ​​40,000m2 and a building area of ​​more than 22,000m2. The products are mainly used for the diversion of the river bed, mining, metallurgy, city planning, power, coal, FGD, petroleum, chemical industry, construction materials, etc. DSC (R) series FGD pump type centrifugal pump, single absorption-stage structure with horizontal and showing advantages of wide consumption, high efficiency and energy saving. Series FGD pumps have a compact and space saving design. As a professional manufacturer of slurry pump and supplier in China, we have developed different materials for DSC (R) Series FGD pumps.

Features of FGD pump
1. CFD flow simulation analysis technology is used to pump wet parts, with reliable design and high efficiency.2. Adjusting the bearing assembly can change the position of the wheels in the cochlea, while maintaining high efficiency pump in working order.
3. DSC (R) Series FGD pumps back side disassembly, have a simple structure and easy to maintain. There is no need to dismantle the suction and discharge pipes.
4. Double-row tapered roller bearings are installed at the end of the pump, a roller bearing on the drive end. The bearings are lubricated with oil, improving their condition and prolonging working life.

5. The mechanical seal specially designed for cartridge mechanical seals used in the pump flue gas desulfurization DSC (R) Series FGD pumps, reliable operation.

Material for DSC (R) Series FGD pump
We have developed a new type of material - duplex phase stainless white iron - which is especially suitable for FGD units. With the anti-abrasion property of duplex stainless steel and the corrosion resistance of high chromium white cast iron, the material is qualified for FGD process.
1. The pump housing, the pump cover and the adapter plate pressure bearing parts, which are made of ductile iron, and lined with rubber.
2. The impeller, suction cover / front liner liner duplex stainless white iron phase.
3. The front liner, the liner back, back liner inserts are made of natural rubber, which has good corrosion resistance, light weight and low cost.
