Our vertical pump program offers the newest and widest range of world class rubber lined slurry pumps for abrasive and difficult pumping applications. Industrial process may create floating foams or froth in some process circuits, which can be very frustrating. In floatation industry, there may be foams in slurries, and then the normal slurry pump may not be suitable for transporting slurries with tough bubbles or froth in mining industry. Our mining froth pump solves this problem, and it is also a type of centrifugal vertical slurry pump.
Application of Mining Froth Pump
This vertical slurry pump can be applied in flotation industrial process, ideal for delivering foaming slurries.
Features of Vertical Slurry Pump
1. This mining froth pump head adopts double-casing design. The pump wet parts are made of Ni-hard and high chromium wear-resistant alloy materials. Funnel charging box is of steel structure. It can be lined according to different kinds of material. The discharge direction of pump can be oriented at intervals of 45°.
2. This mining froth pump can effectively eliminate froth in operation. It’s able to continue working even during shortage of materials.
Typical one
Specification of Rubber Lined Slurry Pump 75DF:
1 Flow rate of the mining froth pump is 10.8-149.4 m³/h
2 The vertical slurry pump head is 6.5-29.5m
3 rotation speed is 700-1500r/min
4 Maximum performance of the mining froth pump is 20-55%.
5 Maximum flow particle size is 38mm
6 Maximum power applicable is 20KW
